TSS0230U RGG

Single Diodes Overview

The TSS0230U is a single-die Schottky barrier rectifier manufactured by Taiwan Semiconductor. It features an average forward current of 200 mA and a repetitive peak reverse voltage of 35 V. The device utilizes a 0603 surface-mount package with matte gold-plated terminals. Key electrical specifications include a maximum forward voltage of 0.6 V at 200 mA, a junction capacitance of 18 pF at 1 MHz, and a peak forward surge current rating of 1 A. The component operates within a junction temperature range of -40°C to +125°C.

Single Diodes Feature Summary

• Low junction capacitance for high-speed switching applications
• Low forward voltage drop to minimize power loss
• Guardring structure for enhanced overvoltage protection
• Designed for automated surface-mount placement

Single Diodes Applications

• Switching power supplies
• Adapters
• Inverters

Single Diodes Procurement Notes

Verify the specific ordering suffix 'RGG' corresponds to the green compound packing code and reel quantity as defined in the manufacturer's documentation. Confirm compliance with RoHS directives and WEEE regulations during procurement. Ensure the selected variant matches the required moisture sensitivity level and halogen-free status specified in the official datasheet.

Single Diodes Selection Notes

Select this component for circuits requiring low stored charge and minimal parasitic capacitance. The 0603 footprint is suitable for space-constrained designs. Evaluate the 35 V reverse voltage rating against peak circuit transients. Consider the 200 mA continuous current limit for thermal management in the target application environment.

Single Diodes Part Context

This part belongs to the TSS0230 series of Schottky barrier diodes from Taiwan Semiconductor. The series is characterized by small surface-mount packages designed for efficiency. The TSS0230U specifically denotes the 35 V voltage rating variant within this product line, utilizing a standard 0603 case configuration.

Single Diodes Replacement Considerations

Consult official substitution lists for verified equivalents. Cross-reference parameters such as forward voltage, reverse leakage, and package dimensions when evaluating alternative components.
