TST04RB01T

Headers, Male Pins Overview

The TST04RB01T is a board-level connector header manufactured by ITT Cannon, LLC. It belongs to the Trident Snap Together (TST) series and features a vertical mounting configuration with four positions. The component utilizes a 5.08 mm (0.200 inch) pitch for contact spacing. It is designed for through-hole installation on printed circuit boards. The receptacle supports a voltage rating of 250 VAC and carries an electrical current rating of up to 13 A. This part serves as a reliable interconnect solution for various industrial and commercial applications requiring secure PCB attachment.

Headers, Male Pins Feature Summary

• Vertical board mount design for direct PCB integration
• Trident Snap Together mechanism for low installed cost assembly
• Robust construction rated for harsh environmental conditions

Headers, Male Pins Applications

• Industrial control systems
• Commercial avionics interconnects
• General purpose PCB wiring harnesses

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official ITT Cannon documentation to confirm exact plating options and material specifications. Ensure compatibility with mating headers from the same TST series family. Confirm that the selected variant meets all required environmental sealing standards for the intended operational environment before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical, four-position header is required for rigid PCB connections. Consider the 5.08 mm pitch requirement and 13 A current capacity during design phase. Evaluate the Trident Snap Together feature for assembly efficiency needs. Verify that the 250 VAC rating aligns with system voltage requirements and that through-hole mounting is feasible within the mechanical constraints of the target enclosure.

Headers, Male Pins Part Context

This connector is part of the Trident Snap Together (TST) rectangular connector family produced by ITT Cannon. The TST series is engineered for board-level applications, offering a balance of performance and ease of assembly. These connectors are widely utilized in sectors such as aerospace, defense, and industrial automation where reliable signal and power transmission is critical under demanding operating conditions.

Headers, Male Pins Replacement Considerations

Cross-reference with TST04RB01Z for alternative configurations within the same series. Verify pin count, pitch, and mounting style match exactly before substitution. Consult official ITT Cannon change notices for any manufacturing updates affecting form, fit, or function.
