TST06RD01T

Headers, Male Pins Overview

The TST06RD01T is a vertical board-level header manufactured by ITT Cannon, LLC. It features six male pins arranged in a single row with a 5.08mm pitch. Designed for PCB mounting, this connector provides reliable electrical interconnection for low-current applications. The component is RoHS-compliant and engineered to meet industrial standards for durability and performance in various electronic systems.

Headers, Male Pins Feature Summary

• Vertical board-mount design for direct PCB integration
• Single-row configuration with six male pin contacts
• RoHS-compliant construction for environmental safety

Headers, Male Pins Applications

• Industrial control panels
• General-purpose electronic assemblies
• Low-voltage signal routing

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official ITT Cannon documentation to ensure authenticity. Confirm that the ordering suffix matches the required contact configuration and housing style. Check for any recent updates to the datasheet regarding compliance or mechanical specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical, single-row header with a 5.08mm pitch is required. Ensure the application current does not exceed the rated capacity of the Trident Snap Together series. Verify that the PCB layout accommodates the specified pin spacing and that the mating connector aligns with the male pin configuration.

Headers, Male Pins Part Context

This part belongs to the Trident Snap Together (TST) series from ITT Cannon. These connectors are designed for low installed cost and high reliability in rectangular applications. The series supports up to 13A and 250V AC, making it suitable for general industrial and commercial interconnect needs where space efficiency and ease of assembly are priorities.

Headers, Male Pins Replacement Considerations

Consult official ITT Cannon cross-reference guides for verified substitutes. Ensure replacement parts maintain the same 6-position count, 5.08mm pitch, and vertical orientation. Verify compatibility with existing PCB footprints and mating hardware before substitution.
