TST09RD01T

Headers, Male Pins Overview

The ITT Cannon TST09RD01T is a vertical pin header connector belonging to the Trident TSTSLIM series. It features a shrouded design with nine contacts arranged in a single row, utilizing a 5.08 mm pitch. The component is engineered for through-hole straight mounting on printed circuit boards, providing reliable wire-to-board interconnection. Constructed for durability in demanding environments, it supports robust mechanical engagement and offers sealing capabilities up to IP69K standards, ensuring resistance to vibration, fluids, and dust.

Headers, Male Pins Feature Summary

• Shrouded header design ensures correct mating alignment and prevents misinsertion
• Vertical orientation facilitates efficient board space utilization
• Through-hole soldering method provides secure mechanical attachment
• High environmental sealing performance suitable for harsh operating conditions

Headers, Male Pins Applications

• Battery management systems
• Brake system control units
• Sensor interface modules
• Industrial control panels

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required contact count and pitch specifications before ordering. Confirm RoHS compliance status if restricted substances are a concern. Ensure the supplier source is authorized to guarantee genuine ITT Cannon components. Check standard lead times as manufacturing delays may occur. Validate that the shrouded configuration aligns with the mating connector housing requirements.

Headers, Male Pins Selection Notes

Select this component when a low-profile, high-density connection is required for PCB assembly. The 5.08 mm pitch accommodates standard wire gauges while maintaining compact dimensions. Consider the shrouded feature for applications where polarity or orientation accuracy is critical. Evaluate the through-hole mounting style against surface-mount alternatives based on mechanical stress requirements and board thickness constraints.

Headers, Male Pins Part Context

This connector belongs to the Trident TSTSLIM series by ITT Cannon, designed for miniaturized interconnect solutions. The series emphasizes reliability in harsh environments, combining compact form factors with robust sealing properties. ITT Cannon utilizes these connectors across aerospace, defense, and industrial sectors, leveraging decades of expertise in durable electrical connections.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available for direct replacement.
