TSW-105-07-S-D-009

Headers, Male Pins Overview

Samtec TSW-105-07-S-D-009 is a classic PCB header strip featuring 10 positions in a dual-row configuration. It utilizes a 2.54 mm (0.1 in) pitch and is designed for through-hole mounting with a straight installation style. The connector employs male pin contacts made of phosphor bronze, finished with gold plating on the mating interface. Electrical ratings include current capacities ranging from 4.3 A to 6.3 A and voltage ratings up to 500 VAC. The housing is constructed from polybutylene terephthalate (PBT) with a UL 94 V-0 flammability rating. Operating temperatures span from -55°C to +125°C.

Headers, Male Pins Feature Summary

• Classic PCB header design suitable for board-to-board and cable connections
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Straight through-hole termination facilitates standard PCB assembly

Headers, Male Pins Applications

• Board-to-Board interconnections
• Cable to Board connections
• General purpose electronic circuit integration

Headers, Male Pins Procurement Notes

Verify component authenticity by cross-referencing the manufacturer part number TSW-105-07-S-D-009 with official Samtec documentation. Confirm that the received hardware matches the specified 10-position, dual-row geometry and 2.54 mm pitch. Ensure compliance with RoHS directives and UL 94 V-0 flammability standards required for the target application environment before final integration.

Headers, Male Pins Selection Notes

Select this component when a standard 2.54 mm pitch header is required for through-hole applications. The dual-row format supports higher density connections compared to single-row alternatives. Verify that the 4.3 A to 6.3 A current rating aligns with the system's electrical load requirements and that the -55°C to +125°C temperature range covers operational extremes.

Headers, Male Pins Part Context

The TSW series represents Samtec's classic line of PCB header strips, widely used for general interconnect needs. This specific model belongs to the TSW family, characterized by its standard pin header configuration. It serves as a fundamental passive component in electronics manufacturing, providing robust mechanical and electrical connections between printed circuit boards or cables.

Headers, Male Pins Replacement Considerations

Compatible substitutes within the same series include TSW-107-07-S-D-005, which offers a similar dual-row through-hole header configuration with comparable pitch and contact materials.
