TSW-105-23-F-S

Headers, Male Pins Overview

The TSW-105-23-F-S is a single-row, through-hole PCB header strip manufactured by Samtec Inc. It features a 0.100" (2.54mm) pitch and contains 23 positions. The connector utilizes phosphor bronze contacts with tin plating for reliable signal transmission. Designed for board-to-board or cable applications, it offers vertical orientation and push-pull fastening. The unit supports solder termination and operates within a temperature range of -55°C to 105°C, ensuring durability in standard electronic environments.

Headers, Male Pins Feature Summary

• Features industry-leading design flexibility with numerous lead styles and pin configurations.
• Utilizes .025" (.635 mm) square post terminals for robust mechanical stability.
• Offers extensive options for optimizing cost and performance through various platings.

Headers, Male Pins Applications

• General purpose board-to-board interconnections
• Cable-to-board connections
• Standard 0.100" pitch application circuits

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating and length variations. Ensure the selected variant matches the required thermal and current ratings for the target application. Cross-reference the official Samtec datasheet for precise dimensional tolerances and mating partner specifications before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a standard 0.100" pitch header is required for general connectivity. Consider the tin-plated contacts for cost-effective solutions where high corrosion resistance is not critical. Evaluate the single-row configuration against space constraints and pin count requirements to ensure optimal board layout efficiency.

Headers, Male Pins Part Context

This part belongs to the TSW series of classic PCB header strips from Samtec. The series is known for providing a wide variety of standard pin counts and terminal lengths. It serves as a fundamental interconnect solution for electronics requiring reliable, low-cost, and flexible connection options across various industries.

Headers, Male Pins Replacement Considerations

Compatible mates include ESQ, LLS, and TSS series headers. Verify that substitute parts maintain the same 0.100" pitch and compatible contact dimensions to ensure proper mechanical fit and electrical continuity without modification.
