TSW-110-08-L-S

Headers, Male Pins Overview

The Samtec TSW-110-08-L-S is a single-row PCB header strip featuring a 2.54 mm (0.100 inch) pitch and ten positions. Designed for through-hole mounting, this right-angle connector utilizes phosphor bronze contacts with a gold plating on the mating interface to ensure reliable signal transmission. The housing is constructed from black polybutylene terephthalate (PBT), rated UL94 V-0 for flammability, and operates within a temperature range of -55°C to +125°C. It supports board-to-board and cable applications.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for space-efficient board layouts
• Gold-plated phosphor bronze contacts for durable electrical connectivity
• Cuttable design allows for flexible position count customization

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General-purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix code against official Samtec documentation to confirm exact pin count, orientation, and termination style. Ensure compatibility with mating socket strips regarding contact length and insulation height. Confirm RoHS3 compliance status if required by project specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row, right-angle male header is required for rigid PCB assembly. Consider the cuttable nature of the TSW series if standard lengths do not match the design footprint. Verify that the 2.54 mm pitch aligns with the target mating connector system and that the through-hole termination method suits the manufacturing process.

Headers, Male Pins Part Context

This part belongs to the TSW Classic PCB Header Strip family from Samtec. The series offers flexible stacking solutions and is widely used in industrial and commercial electronics. The TSW designation indicates a standard tin-plated post variant, while the L-S suffix specifies the single-row, right-angle configuration with no shrouding.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other single-row 2.54mm pitch headers from Samtec such as the TSW-110-08-L-D variants for dual-row needs, or equivalent parts from manufacturers like Molex and TE Connectivity, provided mechanical dimensions and electrical ratings are matched.
