TSW-110-15-F-D

Headers, Male Pins Overview

The TSW-110-15-F-D is a vertical board-to-board or cable header manufactured by Samtec Inc. It features a 2.54 mm (0.100 inch) pitch with 30 total positions arranged in two rows of 15 contacts each. The connector utilizes male pin terminals with tin-plated phosphor bronze contacts and black polybutylene terephthalate (PBT) insulation rated UL94 V-0. Designed for through-hole mounting, it operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Dual-row configuration providing 30 contact positions for high-density interconnection
• Through-hole termination method ensures secure PCB attachment
• Tin-plated phosphor bronze contacts offer reliable conductivity
• Black PBT insulation provides UL94 V-0 flame resistance

Headers, Male Pins Applications

• General-purpose board-to-board connections
• Cable-to-board interconnections
• Industrial control system backplanes
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify the specific suffix code against official documentation to confirm exact terminal length and orientation variations. Confirm that the 'D' designation corresponds to the dual-row layout required for the target application. Ensure compatibility with mating socket series such as TSH or TSS before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a standard 2.54 mm pitch is required for non-high-speed applications. The tin-plated finish is suitable for general environments but may require consideration for corrosive conditions where gold plating is preferred. Verify that the through-hole footprint matches the design constraints and that the current rating meets the circuit requirements.

Headers, Male Pins Part Context

This part belongs to the TSW (Terminal Strip Wire) family, which represents cost-effective terminal strips with a 0.100-inch pitch. The series is designed for general-purpose interconnects, offering various row counts and termination options. It serves as a foundational solution for basic electronic assembly needs where high-frequency performance is not the primary constraint.

Headers, Male Pins Replacement Considerations

Compatible substitutes include the TSH-110-15-F-D for shrouded variants or the TSS-110-15-F-D for surface mount alternatives. Cross-reference with other manufacturers offering 2.54 mm dual-row headers, ensuring identical pin count, pitch, and mounting style are maintained.
