TSW-110-23-L-D

Headers, Male Pins Overview

The Samtec TSW-110-23-L-D is a through-hole, right-angle pin header strip featuring a 0.100 inch (2.54 mm) pitch. It provides 20 positions arranged in a dual row configuration with all pins loaded. The connector utilizes phosphor bronze contacts with tin plating on the mating interface and tail sections. Designed for board-to-board or cable applications, it operates within a temperature range of -55°C to 125°C. The housing is constructed from black polybutylene terephthalate (PBT) rated UL94 V-0.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting for compact vertical integration
• Tin-plated phosphor bronze contacts for reliable conductivity
• Cuttable strip design allows for custom pin count optimization
• UL94 V-0 flammability rating ensures safety compliance

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official datasheets to confirm exact pin configurations and termination lengths. Ensure compatibility with mating socket strips regarding contact retention and alignment. Confirm that the tin plating specification meets the environmental requirements for the intended application environment.

Headers, Male Pins Selection Notes

Select this model when right-angle orientation and through-hole termination are required for a 20-position dual-row connection. Consider the tin plating option if gold plating is not necessary for corrosion resistance. Evaluate the cuttable nature of the strip to determine if fewer positions can be utilized to reduce cost and profile height.

Headers, Male Pins Part Context

This component belongs to the TSW series of classic PCB header strips manufactured by Samtec Inc. The series offers extensive flexibility in lead styles, plating options, and pin counts. It is designed for standard 0.100 inch pitch applications commonly found in industrial and commercial electronics.

Headers, Male Pins Replacement Considerations

Cross-reference with other TSW-110-xx-L-D variants for different pin counts. Verify mechanical dimensions against competitors' right-angle headers with identical 2.54 mm pitch and tin-plated through-hole tails.
