TSW-117-08-T-S-RA

Headers, Male Pins Overview

Samtec TSW-117-08-T-S-RA is a single-row male pin header connector with 8 positions and a 2.54 mm (0.100 inch) pitch. Designed for right-angle through-hole mounting, it features phosphor bronze contacts with tin plating on the tails and matte tin over nickel on the mating interface. The insulator is constructed from black polybutylene terephthalate (PBT) rated UL94 V-0. It operates within a temperature range of -55°C to +105°C and supports voltages up to 400 VAC.

Headers, Male Pins Feature Summary

• Right-angle through-hole termination for compact board-to-board or cable connections
• Tin-plated phosphor bronze contacts ensure reliable conductivity
• UL94 V-0 rated PBT insulation provides flame resistance
• Standard 0.100 inch pitch facilitates widespread compatibility

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board assemblies
• General-purpose electronic circuitry

Headers, Male Pins Procurement Notes

Verify the specific contact plating configuration against official Samtec datasheets, as suffixes dictate surface treatment. Confirm that the tin-plated variant meets the required corrosion resistance and mating cycle specifications for the target application environment before finalizing procurement.

Headers, Male Pins Selection Notes

Select this model when a low-profile, single-row right-angle header is required. Ensure the design accommodates the standard 0.100 inch pitch and through-hole footprint. Verify that the tin-plated contact finish aligns with the environmental conditions and mating partner requirements.

Headers, Male Pins Part Context

This component belongs to the TSW Classic PCB Header Strips series by Samtec Inc. The series offers versatile straight and right-angle configurations in single, double, and triple rows. These headers are widely utilized for general interconnect needs across various industrial and consumer electronics applications.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Samtec TSW series headers with matching 8-position count, single row layout, and right-angle through-hole termination. Cross-reference physical dimensions and electrical ratings to ensure interchangeability.
