TSW-124-08-S-D

Headers, Male Pins Overview

The Samtec TSW-124-08-S-D is a classic PCB header strip featuring a 2.54 mm (0.1 in) pitch and 48 positions arranged in two rows. Designed for through-hole mounting with a straight installation angle, it utilizes phosphor bronze contacts with gold plating on the mating section. The connector supports board-to-board and cable applications within an operating temperature range of -55°C to +125°C. It employs Polybutylene Terephthalate (PBT) insulation rated UL 94 V-0. Electrical ratings include current values from 4.3 A to 6.3 A and voltage ratings up to 550 VAC.

Headers, Male Pins Feature Summary

• Features a standard 0.100 inch square pin system compatible with industry-standard sockets.
• Provides flexible design options including various termination lengths and plating configurations.
• Supports vertical or right-angle assembly orientations for diverse board layout requirements.

Headers, Male Pins Applications

• Board-to-Board interconnections
• Cable-to-Board connections
• General purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm contact plating thickness, terminal length, and row configuration. Ensure the selected variant matches the required thermal and electrical specifications for the target application environment. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and compliance status prior to procurement.

Headers, Male Pins Selection Notes

Select this component when a high-density, double-row header with reliable gold-plated contacts is required for robust signal integrity. Consider the available terminal length options to accommodate different board stack heights or mating connector profiles. Evaluate the operating temperature range and flammability rating to ensure compatibility with the assembly process and end-use environmental conditions.

Headers, Male Pins Part Context

This part belongs to the TSW series of classic PCB header strips from Samtec. The series offers extensive customization in terms of lead style, plating, and terminal configuration. It is designed for general-purpose interconnect solutions requiring durable through-hole performance and standardized spacing.

Headers, Male Pins Replacement Considerations

Consult official Samtec substitution guides for verified equivalent parts. Generic alternatives may not match the precise dimensional tolerances or material specifications of the original TSW series components.
