TSW-133-06-S-S

Headers, Male Pins Overview

The Samtec TSW-133-06-S-S is a single-row PCB header strip featuring 33 positions with a 2.54 mm (0.100 inch) pitch. It utilizes through-hole termination for vertical board mounting and employs phosphor bronze contacts with gold plating on the mating interface. The housing is constructed from black polybutylene terephthalate (PBT), rated UL94 V-0, supporting an operating temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Vertical through-hole mounting configuration for standard PCB integration
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Single-row design with 0.100-inch spacing for classic interconnect applications

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm contact plating thickness and terminal length variations. Ensure the selected variant matches the required current rating and thermal performance for the target application environment before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component for standard 0.100-inch pitch applications requiring vertical orientation. Confirm that the single-row layout fits the available PCB footprint and that the through-hole soldering process aligns with the manufacturing capabilities of the assembly line.

Headers, Male Pins Part Context

This part belongs to the TSW Classic PCB Header Strips series by Samtec. The series offers extensive design flexibility with various terminal lengths and configurations, serving as a foundational interconnect solution for general-purpose electronics where standard spacing and robust mechanical retention are required.

Headers, Male Pins Replacement Considerations

Cross-reference with other TSW-133 variants or equivalent 33-position headers from manufacturers like Harwin, ensuring identical pitch, row count, and mounting style compatibility.
