TSW-140-08-T-D

Headers, Male Pins Overview

The Samtec TSW-140-08-T-D is a classic PCB header strip featuring a 2.54 mm (0.1 in) pitch and an 80-position, two-row configuration. Designed for through-hole mounting with a straight installation angle, it utilizes tin-plated phosphor bronze contacts. The connector employs a Polybutylene Terephthalate (PBT) insulator rated UL 94 V-0 for flammability. It supports board-to-board and cable applications within a temperature range of -55°C to +105°C.

Headers, Male Pins Feature Summary

• Offers industry-leading design flexibility with extensive options for pin counts, terminal lengths, and lead styles.
• Features a .025" (.635 mm) square post contact system optimized for reliable mating.
• Provides multiple plating options to optimize cost and performance characteristics.

Headers, Male Pins Applications

• Board-to-Board interconnections
• Cable connections
• General purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Samtec catalog to ensure correct termination length and contact plating. Confirm that the standard bulk packaging aligns with assembly requirements. Cross-reference the RoHS compliance status and moisture sensitivity level prior to procurement to ensure compatibility with manufacturing processes.

Headers, Male Pins Selection Notes

Select this component for applications requiring a standard 0.100 inch pitch with high position density. Ensure the through-hole footprint matches the PCB layout constraints. Verify that the operating temperature range and current ratings meet the system's electrical demands. Consider the straight orientation for vertical stacking or panel mounting scenarios.

Headers, Male Pins Part Context

This part belongs to the TSW series of traditional PCB header strips manufactured by Samtec Inc. The series is characterized by its versatility in providing various pin configurations and termination options for standard spacing applications. It serves as a fundamental interconnect solution for general electronic hardware designs.

Headers, Male Pins Replacement Considerations

TSW-140-07-S-D

Headers, Male Pins FAQ

What is the contact material used in this header?

The contacts are made from phosphor bronze with a tin plating finish.

Is this connector available in a right-angle configuration?

No, the TSW-140-08-T-D is specified with a straight installation angle; right-angle variants use different model suffixes.
