TTETBEJANF-12.800000

Oscillators Overview

The TTETBEJANF-12.800000 is a high-precision Voltage Controlled Temperature Compensated Crystal Oscillator (TCXO) manufactured by Taitien. It operates at a nominal frequency of 12.8 MHz and utilizes CMOS output logic. The device is designed for surface mount installation within a compact 4-SMD, No Lead Exposed Pad package. It functions reliably across an extended industrial temperature range from -40°C to +85°C and requires a supply voltage of 3.3V. The oscillator incorporates internal temperature compensation to maintain frequency stability under varying thermal conditions.

Oscillators Feature Summary

• Integrated temperature compensation circuitry ensures stable frequency performance across wide thermal variations.
• CMOS output interface provides digital signal compatibility with standard logic circuits.
• Compact surface-mount footprint facilitates automated assembly and space-constrained PCB layouts.

Oscillators Applications

• Telecommunications base station synchronization
• Industrial control system timing references
• Automotive electronics clock generation

Oscillators Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm pinout configuration and output type. Ensure the selected variant matches the required supply voltage and operating temperature range for the target application environment. Cross-reference the part number with the latest revision history to avoid obsolete components.

Oscillators Selection Notes

Select this component when precise frequency stability is required in thermally variable environments without external compensation networks. The CMOS output simplifies interfacing with microcontrollers and digital processors. Evaluate the exposed pad requirement for thermal management and grounding strategies during the PCB design phase to ensure optimal electrical performance.

Oscillators Part Context

This TCXO belongs to Taitien's portfolio of precision frequency control products. The company specializes in quartz-based oscillators for demanding applications. This model represents a surface-mount solution designed to replace larger through-hole or older SMD packages while maintaining high accuracy standards for modern electronic systems.

Oscillators Replacement Considerations

Consult the official replacement guide for direct substitutes. Verify that alternative parts match the 12.8 MHz frequency, 3.3V supply, and CMOS output characteristics. Ensure physical dimensions and pin assignments are compatible with existing footprints.
