TUSB1106RTZR

Drivers, Receivers, Transceivers Overview

The TUSB1106RTZR is an advanced universal serial bus transceiver manufactured by Texas Instruments, designed for USB 2.0 compliance. It supports full-speed data transmission at a rate of 12 Mb/s and operates with a supply voltage range of 1.65 V to 3.6 V. The device features integrated ESD protection and functions within an operating temperature range of -40°C to +85°C. Packaged in a compact 16-UQFN (2.6x1.8 mm) surface-mount format, it draws approximately 6 mA during operation. This half-duplex transceiver integrates driver and receiver circuits into a single unit.

Drivers, Receivers, Transceivers Feature Summary

• Supports USB 2.0 full-speed communication protocols
• Integrates electrostatic discharge protection mechanisms
• Provides half-duplex signal transmission capabilities

Drivers, Receivers, Transceivers Applications

• Universal Serial Bus peripheral connectivity
• Portable electronic device interface design
• Embedded system host connections

Drivers, Receivers, Transceivers Procurement Notes

Verify the specific suffix RTZR against official Texas Instruments documentation to confirm reel packaging specifications and tape dimensions. Ensure compatibility with automated pick-and-place equipment requirements. Cross-reference the manufacturer part number with authorized distributor catalogs to validate authenticity and traceability before procurement.

Drivers, Receivers, Transceivers Selection Notes

Select this component when designing systems requiring USB 2.0 full-speed interfaces with low power consumption constraints. The UQFN package suits space-constrained layouts. Verify that the 1.65 V minimum supply voltage aligns with the target system's power rails. Confirm thermal management strategies meet the specified operating temperature limits for the intended environment.

Drivers, Receivers, Transceivers Part Context

This component belongs to the TUSB1106 series of advanced USB transceivers from Texas Instruments. It shares core functional characteristics with variants like the TUSB1106RSVR but differs in packaging configuration. The series targets applications needing reliable USB connectivity with integrated protection features in small form factors.

Drivers, Receivers, Transceivers Replacement Considerations

The TUSB1106RSVR serves as a direct functional alternative within the same product family. Verify pinout compatibility and package dimensions before substitution. Ensure the replacement variant meets all electrical specifications required by the original design.
