TVP06B181A-HF

TVP06B181A-HF is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Comchip Technology. Its product description is TVS DIODE 154VWM 246VC DO214AA. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for TVP06B181A-HF

• Description：TVS DIODE 154VWM 246VC DO214AA
• Series：-
• Mfr：Comchip Technology
• Package：Tape & Reel (TR)
• Type：Zener
• Bidirectional Channels：-
• Voltage - Reverse Standoff (Typ)：154V
• Voltage - Breakdown (Min)：171V
• Voltage - Clamping (Max) @ Ipp：246V
• Current - Peak Pulse (10/1000µs)：2.44A
• Power - Peak Pulse：600W
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：-
• Operating Temperature：-55°C ~ 150°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：DO-214AA, SMB
• Supplier Device Package：DO-214AA (SMB)
• Unidirectional Channels：1
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for TVP06B181A-HF
