TW1.8-5-5

TW1.8-5-5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Polytron. Its product description is DC DC CONVERTER +/-5V 1.8W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TW1.8-5-5

• Description：DC DC CONVERTER +/-5V 1.8W
• Series：TW3 (3W)
• Mfr：Polytron
• Package：Tray
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：4.75V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：5V
• Voltage - Output 2：-5V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：180mA, 180mA
• Power (Watts)：1.8 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-25°C ~ 71°C
• Efficiency：55%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 12 Leads
• Size / Dimension：1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for TW1.8-5-5
