TWA8-24S5

TWA8-24S5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Polytron. Its product description is DC DC CONVERTER 5V 7.5W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TWA8-24S5

• Description：DC DC CONVERTER 5V 7.5W
• Series：TWA8 (8W)
• Mfr：Polytron
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：36V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1.5A
• Power (Watts)：7.5 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：Adjustable Output, Remote On/Off
• Operating Temperature：-25°C ~ 71°C
• Efficiency：82%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 9 Leads
• Size / Dimension：1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
