TX32-33025S-12.288-X-R

Oscillators Overview

The TX32-33025S-12.288-X-R is a temperature-compensated crystal oscillator (TCXO) manufactured by Aker Technology Corp. It operates at a nominal frequency of 12.288 MHz and utilizes a clipped sine wave output signal. The device is designed for surface-mount applications, featuring a compact 4-SMD, No Lead package configuration. It requires a supply voltage of 3.3V to function correctly. The component is supplied in tape and reel packaging for automated assembly processes.

Oscillators Feature Summary

• Temperature-compensated design ensures stable frequency performance across operating conditions
• Compact surface-mount form factor suitable for space-constrained circuit boards
• Clipped sine wave output interface compatible with standard digital logic inputs

Oscillators Applications

• Telecommunications equipment requiring precise timing references
• Data storage and delivery systems needing stable clock signals
• Instrumentation and security systems utilizing microprocessor-based architectures

Oscillators Procurement Notes

Verify the specific output waveform type and supply voltage requirements against your system design before ordering. Confirm that the 4-SMD no-lead package dimensions align with your PCB footprint specifications. Ensure compatibility with the 3.3V power rail intended for the oscillator circuit. Check that the clipped sine wave output meets the input threshold requirements of the downstream load.

Oscillators Selection Notes

Select this component when a stable 12.288 MHz reference is required in a small form factor. Consider the TCXO technology if environmental temperature variations are present in the application environment. Evaluate the 3.3V supply constraint to ensure it matches the available power distribution network. Assess the clipped sine wave output characteristics against the noise immunity requirements of the receiving circuitry.

Oscillators Part Context

This oscillator belongs to the TX32 series from Aker Technology Corp, which specializes in frequency control solutions. The company has been manufacturing crystal and oscillator products since 1990, serving industries such as automotive, telecommunications, and computer products. This specific model represents their capability to provide miniature oscillators for demanding electronic applications.

Oscillators Replacement Considerations

Consult official cross-reference data or manufacturer substitution guides to identify equivalent parts. Verify that any substitute maintains the 12.288 MHz frequency, 3.3V operation, and 4-SMD package. Ensure the replacement part offers comparable frequency stability and temperature compensation characteristics.
