TZKTADSANF-50.000000

Oscillators Overview

TZKTADSANF-50.000000 is a temperature-compensated crystal oscillator (TCXO) manufactured by Taitien, operating at a nominal frequency of 50 MHz. It delivers a clipped sine wave output and functions with a supply voltage of 1.8V. The device exhibits high frequency stability of ±500ppb across an operating temperature range of -30°C to 85°C. It is housed in a compact 6-SMD no-lead package measuring 2.05mm x 1.65mm.

Oscillators Feature Summary

• Temperature compensation ensures stable frequency performance across varying thermal conditions
• Compact surface-mount packaging facilitates integration into space-constrained circuit designs
• Low supply current consumption supports energy-efficient system operation

Oscillators Applications

• Telecommunications equipment requiring precise timing signals
• Portable electronic devices utilizing low-voltage power supplies
• Automotive infotainment and navigation systems

Oscillators Procurement Notes

Verify the specific output waveform compatibility with downstream logic circuits, as the clipped sine wave may require additional conditioning depending on the application design. Confirm that the 1.8V supply voltage aligns with the target system's power rails before finalizing component selection for production integration.

Oscillators Selection Notes

Select this component when high frequency stability is critical within a limited temperature window. The 1.8V supply requirement dictates the necessary power management architecture. Ensure the PCB layout accommodates the 6-SMD footprint dimensions to maintain signal integrity and mechanical reliability during assembly processes.

Oscillators Part Context

This TCXO belongs to Taitien's oscillator lineup, which includes various timing solutions such as VCXOs and OCXOs. These products support applications in aerospace and industrial sectors where reliable clock generation is essential. The TZKT series specifically targets markets demanding precision timing in compact form factors.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify pinout and electrical specifications against potential alternatives to ensure functional compatibility without redesigning the host circuit board.
