UCB10-220T-RC

Overview

The UCB10-220T-RC is a ferrite bead chip manufactured by Allied Components International. It features a 22 Ohm impedance rating and is housed in an 0806 surface-mount package. The component has a maximum DC resistance of 12 milliohms and supports a current rating of up to 6 Amperes. It is designed for single-circuit applications within the ferrite beads and chips product category.

Feature Summary

• Provides electromagnetic interference suppression through high-frequency impedance characteristics
• Supports high-current operation with a maximum rating of 6 Amperes
• Features low DC resistance for minimal signal loss in power lines

Applications

• Power supply line filtering
• High-speed data line noise suppression
• General-purpose EMI suppression in compact electronic devices

Procurement Notes

Verify the specific datasheet version for the UCB10-220T-RC to confirm impedance tolerance and thermal ratings. Ensure compatibility with standard 0806 reflow soldering profiles. Cross-reference manufacturer documentation for handling precautions regarding electrostatic discharge during assembly and storage.

Selection Notes

Select this component when a 22 Ohm impedance at the target frequency is required for noise attenuation. The 0806 footprint suits space-constrained designs. Verify that the 6A current rating meets the circuit's peak load requirements without exceeding the thermal limits defined in the official specifications.

Part Context

This part belongs to the Ultra Current Beads series from Allied Components International. It is categorized under ferrite beads and chips, distinct from wirewound inductors or capacitors. The UCB10 prefix indicates the series family, while the suffix specifies the impedance and package type.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult the manufacturer for direct equivalents or verify pin-compatible alternatives based on identical impedance and current ratings.
