UFDX9999

Overview

The MtronPTI UFDX9999 is a C-band cavity diplexer/splitter assembly designed for rugged, high-performance communication links. The unit measures 97 x 64 x 32 mm and weighs 0.4 kg. It features SMA female connectors as standard. Electrical specifications include a Passband 1 frequency range of 14.4 GHz to 14.83 GHz and a Passband 2 range of 15.15 GHz to 15.35 GHz. Insertion loss is less than 1.0 dB, with return loss at all ports exceeding 15 dB.

Feature Summary

• Cavity construction for high performance in rugged environments
• Dual passband capability for diplexing or splitting functions
• Standard SMA female connector interface

Applications

• Rugged communication links
• High-performance RF signal routing
• C-band frequency separation systems

Procurement Notes

Verify the specific suffix (e.g., -002) against the required frequency bands and connector type. Confirm physical dimensions and weight requirements for integration. Ensure compatibility with existing SMA interfaces. Request official datasheets for precise electrical validation before procurement.

Selection Notes

Select this component when C-band isolation and low insertion loss are critical. Consider the physical size constraints due to the cavity design. Verify that the SMA connectors meet system interface standards. Evaluate ruggedness requirements for the intended operational environment.

Part Context

MtronPTI manufactures this device as part of its portfolio supporting common data links. The product line includes various diplexers and filters for microwave applications. This specific model addresses needs for reliable signal separation in demanding conditions.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify exact electrical parameters and mechanical fit before considering alternative models from other manufacturers.
