ULTSHC-103-D-10-310-T-LF

Headers, Male Pins Overview

The ULTSHC-103-D-10-310-T-LF is a male header connector manufactured by Major League Electronics. It features a through-hole mounting style with a .100 inch (2.54mm) pitch. The component has a double row configuration containing three positions per row, resulting in a total of six pins. The tail length is specified as 0.310 inches. This connector is designed for reliable electrical interconnection in electronic assemblies requiring standard spacing and robust mechanical attachment.

Headers, Male Pins Feature Summary

• Double row header configuration for increased pin density
• Through-hole mounting for secure board attachment
• Standard .100 inch pitch spacing

Headers, Male Pins Applications

• General purpose electronic circuit boards
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific tail length and contact plating requirements against your design specifications before procurement. Ensure that the supplier provides official documentation confirming the part number matches the exact physical dimensions and material composition required for your assembly process.

Headers, Male Pins Selection Notes

Select this component when a double-row male header with a .100 inch pitch is required. Consider the through-hole mounting method and the specific tail length of 0.310 inches to ensure compatibility with your PCB layout and housing constraints.

Headers, Male Pins Part Context

This part belongs to the ULTSHC series of headers from Major League Electronics. The series offers various configurations including single and double rows with different pin counts and tail lengths. The ULTSHC-103-D-10-310-T-LF specifically denotes a double row, three-position header with a defined tail length.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other .100 inch pitch double row headers from manufacturers such as Samtec or TE Connectivity. Verify that any replacement part matches the pin count, row configuration, and mounting style to ensure functional equivalence.
