ULTSHC-136-S-03-105-F-LF

Headers, Male Pins Overview

The ULTSHC-136-S-03-105-F-LF is a board connector manufactured by Major League Electronics. It features 36 contacts arranged in a single row with a 0.1 inch (2.54mm) pitch. The component is designed for right-angle through-hole mounting on a printed circuit board. Contact finishes include gold plating over nickel for the mating surface and tin/lead solder for termination, ensuring compliance with lead-free and RoHS standards. The insulator material is polyamide (PA6T/Nylon 6T), providing structural integrity.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for PCB integration
• Gold-plated contact finish over nickel barrier for reliable signal transmission
• Polyamide insulation material offering thermal stability
• Lead-free and RoHS compliant construction

Headers, Male Pins Applications

• High-density electronic assemblies requiring 36-position interconnects
• Industrial control boards utilizing standard 0.1 inch spacing
• Consumer electronics hardware with right-angle header requirements

Headers, Male Pins Procurement Notes

Verify that the specific suffix LF confirms lead-free status against current manufacturer specifications. Ensure the ordering part number matches the exact pin count and pitch requirements for the target design. Confirm compatibility with mating connectors regarding height and latch mechanisms if applicable. Cross-reference the datasheet revision date to ensure all electrical and mechanical parameters are up to date before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a 36-position male header is required for right-angle board-to-board or wire-to-board connections. The 0.1 inch pitch is standard for many legacy and industrial systems. Consider the polyamide insulation material for applications requiring specific thermal ratings. Verify that the through-hole mounting style aligns with the PCB fabrication capabilities and assembly processes available.

Headers, Male Pins Part Context

This part belongs to the ULTSHC series of rectangular connectors from Major League Electronics. The series typically offers various position counts and pitch options. This specific model represents a high-pin-count variant suitable for complex signal routing. The product line focuses on durable, standard-pitch connectors for general electronic applications.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 36-position count, 0.1 inch pitch, and right-angle through-hole form factor. Check for equivalent gold-over-nickel contact finishes and polyamide insulation materials. Verify that any alternative part maintains RoHS compliance and similar physical dimensions for panel fitment.
