UM3608QA

Overview

The UM3608QA is a non-inverting transceiver logic IC manufactured by Union Semiconductor International Limited. It features a single element with eight bits per element and provides three-state outputs. The device operates within a supply voltage range of up to 5.5V and is housed in a compact 24-QFN package measuring 3.5x5.5 mm. This component is designed for digital signal transmission applications requiring non-inverted logic levels.

Feature Summary

• Non-inverting signal transmission capability
• Three-state output configuration for bus sharing
• Compact 24-QFN surface-mount packaging

Applications

• Digital data bus interfaces
• Microcontroller peripheral expansion
• Logic level translation circuits

Procurement Notes

Verify the manufacturer designation as Union Semiconductor International Limited against official documentation. Confirm the package type is 24-QFN (3.5x5.5) and the electrical specification matches the 5.5V rating. Ensure the RoHS compliance status aligns with project requirements before procurement.

Selection Notes

Select this component when a non-inverting transceiver with three-state outputs is required for low-voltage digital systems. The 24-QFN package suits space-constrained designs. Verify compatibility with the target system's voltage levels and interface protocols prior to integration.

Part Context

This part belongs to the logic IC category, specifically within buffers, drivers, receivers, and transceivers. It serves as a digital interface component for signal integrity management in electronic circuits.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided source material.
