Product Detailed Parameters
- Description：DIODE ZENER ARRAY 36V UMD3
- Series：-
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Configuration：1 Pair Common Anode
- Voltage - Zener (Nom) (Vz)：36 V
- Tolerance：-
- Power - Max：200 mW
- Impedance (Max) (Zzt)：-
- Current - Reverse Leakage @ Vr：-
- Operating Temperature：-
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- pa_package-case：
- Supplier Device Package：UMD3
- Voltage - Forward (Vf) (Max) @ If：-
Download product information
Overview
The UMZ36NT106 is a low capacitance Zener diode manufactured by ROHM Semiconductor, designed for terminal protection applications. It features an A-Common configuration within a UMD3 (SOT-323) surface-mount package. The device specifies a typical Zener voltage of 36V, with a minimum of 35.07V and a maximum of 36.87V at a test current of 5mA. It supports a power dissipation of 200mW and operates within a junction temperature range up to 150°C. Storage temperatures span from -55°C to 150°C. The component complies with RoHS standards and meets the AEC-Q101 automotive grade standard.
Feature Summary
- AEC-Q101 qualified for automotive reliability
- Low capacitance design for high-speed signal integrity
- Compact SOT-323 plastic package
Applications
- Terminal protection devices
- Automotive electronics circuits
- ESD protection interfaces
Procurement Notes
Verify the specific ordering suffix against official documentation, as availability may vary between tape-and-reel formats. Confirm compliance with current environmental directives and ensure the component status aligns with project lifecycle requirements before finalizing procurement plans.
Selection Notes
Select this component when AEC-Q101 qualification is mandatory for automotive terminals. Ensure the 36V breakdown voltage matches the circuit's clamping requirements. Verify that the 200mW power rating suffices for the expected transient energy levels in the target application environment.
Part Context
This part belongs to ROHM's UMZ series of low capacitance Zener diodes. These components are engineered specifically for protecting sensitive electronic interfaces against electrostatic discharge and electrical fast transients while maintaining signal integrity in compact form factors.
Replacement Considerations
Check for direct substitutes with identical pinouts and package dimensions. Verify that alternative parts meet the same AEC-Q101 automotive grade standards and match the 36V Zener voltage tolerance specifications.
