UT2024-007

Overview

The Triad Magnetics UT2024-007 is a switchmode/high frequency common mode inductor designed for noise suppression. It features an inductance of 4.5 mH and a current rating of 600 mA. The component has a maximum DC resistance of 750 mOhm. It utilizes a horizontal, 4 PC pin lead style for surface or through-hole integration.

Feature Summary

• Provides common mode noise filtering for high-frequency applications
• Constructed with horizontal 4-pin configuration for board mounting
• Rated for 600 mA current handling capability

Applications

• Switchmode power supply input/output filtering
• High-frequency signal line noise suppression
• EMI reduction in electronic circuits

Procurement Notes

Verify the specific datasheet version to confirm mechanical dimensions and thermal ratings. Ensure the 600 mA current rating aligns with the operational requirements of the target circuit. Confirm that the horizontal 4-pin package fits the designated PCB footprint without interference from adjacent components.

Selection Notes

Select this component when a 4.5 mH common mode choke is required for high-frequency noise attenuation. The 600 mA rating suits moderate current applications. Verify compatibility with the operating frequency range specified in the manufacturer's documentation to ensure effective impedance characteristics.

Part Context

This component belongs to the Triad Magnetics chokes and inductors portfolio. It is categorized under switchmode and high-frequency common mode inductors. The UT2024 series provides solutions for electromagnetic interference mitigation in compact electronic designs requiring reliable noise suppression.

Replacement Considerations

Consult official Triad Magnetics substitution guides for verified equivalents. Ensure replacement parts match the 4.5 mH inductance, 600 mA rating, and 4-pin horizontal form factor. Cross-reference datasheets for dimensional and electrical compliance before implementation.
