VCM7104-RC

$8.08

Description：CMC 2.55MH 1A 2LN TH
Series：-
Mfr：Allied Components International
Package：Tray

SKU:ce7e1d3cb1b7 Category: Common Mode Chokes Brand: Allied Components International

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 2.55MH 1A 2LN TH
Series：-
Mfr：Allied Components International
Package：Tray
Filter Type：-
Number of Lines：2
Current Rating (Max)：1A
DC Resistance (DCR) (Max)：100mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 105°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.700" Dia x 0.450" L (17.78mm x 11.43mm)
Height (Max)：-
Package / Case：Vertical, No Base, 4 PC Pin
Inductance @ Frequency：2.55 mH @ 1 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

VCM7104-RC

Overview

The VCM7104-RC is a common mode choke manufactured by Allied Components International. It features a 2.55 mH inductance and supports a current rating of 1 A. The component utilizes a two-line configuration for noise suppression. It is designed for through-hole mounting, facilitating integration into printed circuit boards. This electromagnetic interference filter is engineered to reduce noise in electronic circuits.

Feature Summary

Provides common mode noise suppression for electronic signals
Supports through-hole mounting for PCB integration
Features a two-line configuration for differential signal handling

Applications

Power supply filtering
Battery charger circuits
Portable device noise reduction

Procurement Notes

Verify the manufacturer datasheet for precise electrical characteristics and mechanical dimensions before implementation. Confirm that the through-hole package matches the target PCB layout requirements. Ensure the 1 A current rating and 2.55 mH inductance align with the specific circuit design constraints to guarantee effective electromagnetic interference performance.

Selection Notes

Select this component when designing circuits requiring common mode noise attenuation for low-current applications. The through-hole format is suitable for prototyping or high-reliability assemblies where surface mount options are not preferred. Evaluate the 2.55 mH value against the frequency spectrum of the noise to be suppressed.

Part Context

This part belongs to the VCM710 series of common mode chokes from Allied Components International. The series offers various inductance values and current ratings for different EMI suppression needs. The VCM7104-RC specifically addresses applications requiring moderate inductance with through-hole compatibility.

Replacement Considerations

Consult official distributor databases for cross-reference data. Verify equivalent components based on matching inductance, current rating, and package type. Ensure any substitute maintains the same electromagnetic interference suppression capabilities.
