VCM7111-RC

$5.74

Description：CMC 850UH 3A 2LN TH
Series：-
Mfr：Allied Components International
Package：Tape & Reel (TR)

SKU:270973ed3682 Category: Common Mode Chokes Brand: Allied Components International

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 850UH 3A 2LN TH
Series：-
Mfr：Allied Components International
Package：Tape & Reel (TR)
Filter Type：-
Number of Lines：2
Current Rating (Max)：3A
DC Resistance (DCR) (Max)：0.03mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 105°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.600" Dia x 0.450" W (15.24mm x 11.43mm)
Height (Max)：-
Package / Case：Vertical, No Base, 4 PC Pin
Inductance @ Frequency：850 µH @ 1 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

VCM7111-RC

Overview

The VCM7111-RC is a through-hole common mode choke manufactured by Allied Components International. It features an inductance of 850 µH and supports a current rating of 3 A. The component utilizes a two-line configuration designed for electromagnetic interference suppression. Its physical dimensions are specified as 0.600 inches in diameter by 0.450 inches in width, equivalent to 15.24 mm by 11.43 mm. The device exhibits a direct current resistance of 0.03 mOhm. It complies with lead-free and RoHS standards.

Feature Summary

Two-line common mode filtering architecture
Through-hole mounting construction
Lead-free and RoHS compliant manufacturing

Applications

Electromagnetic interference suppression in electronic circuits
Signal integrity protection in data lines
Power supply noise reduction applications

Procurement Notes

Verify the specific manufacturer datasheet for the VCM7111-RC to confirm electrical characteristics and mechanical drawings. Ensure that the required current rating and inductance values align with the design specifications. Check for compliance with environmental regulations such as RoHS if applicable to the target market. Confirm package type compatibility with the intended PCB layout before finalizing procurement.

Selection Notes

Select this component based on its 850 µH inductance and 3 A current handling capability. Consider the through-hole form factor when designing the circuit board layout. Evaluate the low DC resistance for minimal power loss requirements. Compare against other common mode chokes if higher current or different inductance values are necessary for the specific application environment.

Part Context

Allied Components International specializes in magnetic products including inductors, ferrite beads, and custom magnetics. The VCM7111-RC belongs to their series of common mode chokes designed for general-purpose filtering. This component serves as a passive filter element within electronic assemblies to mitigate conducted emissions.
