VFHV1111C-3BY2B-TR

$0.24

Description：LED RED DIFFUSED 1608 SMD
Series：-
Mfr：Stanley Electric Co
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:5bb265c66185 Category: LED Indication - Discrete Brand: Stanley Electric Co

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

VFHV1111C-3BY2B-TR is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Stanley Electric Co. Its product description is LED RED DIFFUSED 1608 SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for VFHV1111C-3BY2B-TR

Description：LED RED DIFFUSED 1608 SMD
Series：-
Mfr：Stanley Electric Co
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Red
Configuration：Standard
Lens Color：White
Lens Transparency：Diffused
Millicandela Rating：91mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.10mm x 0.80mm
Voltage - Forward (Vf) (Typ)：1.9V
Current - Test：20mA
Viewing Angle：140°
Mounting Type：Surface Mount
Wavelength - Dominant：615nm
Wavelength - Peak：624nm
Features：-
Package / Case：0603 (1608 Metric)
Supplier Device Package：1608
Size / Dimension：1.60mm L x 0.80mm W
Height (Max)：0.80mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for VFHV1111C-3BY2B-TR

VFHV1111C-3BY2B-TR

LED Indication - Discrete Overview

VFHV1111C-3BY2B-TR is a single-color surface-mount LED manufactured by Stanley Electric Co. It features a 0603 (1608 metric) package with a rectangular lens shape and diffused transparency. The component emits red light at a peak wavelength of 624 nm, with a typical forward voltage of 1.9 V and a test current of 20 mA. It offers a luminous intensity of 420 mcd and operates within a temperature range of -40°C to +85°C. The device complies with RoHS standards and has a moisture sensitivity level of 3.

LED Indication - Discrete Feature Summary

Surface-mount construction in a compact 0603 package for automated assembly
Diffused lens design providing wide viewing angles for indicator applications
Red emission optimized for standard visual status indication
Compliant with environmental regulations including RoHS

LED Indication - Discrete Applications

Electronic equipment status indicators
Control panel signal lights
Consumer appliance front panels
Medical device operational displays

LED Indication - Discrete Procurement Notes

Verify the specific suffix '3BY2B' against official datasheets to confirm lens color and intensity binning. Confirm lead times as manufacturing schedules fluctuate. Ensure ESD handling protocols are followed during storage and assembly due to moisture sensitivity classification.

LED Indication - Discrete Selection Notes

Select this component when a low-profile red SMD LED is required for space-constrained designs. Compare luminous intensity requirements against the 420 mcd specification. Consider thermal management capabilities within the specified operating temperature range for high-reliability applications.

LED Indication - Discrete Part Context

This part belongs to Stanley Electric's VFHV series of single-color LEDs. The series is characterized by standardized footprints and electrical parameters suitable for mass production. It represents a common solution for general-purpose red signaling in modern electronics.
