VFWLF19-223T

$3.27

Description：CMC 22.5MH 1.5A 2LN THROUGH HOLE
Series：VFWLF19
Mfr：Allied Components International
Package：Tray

SKU:0475fa9799b4 Category: Common Mode Chokes Brand: Allied Components International

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 22.5MH 1.5A 2LN THROUGH HOLE
Series：VFWLF19
Mfr：Allied Components International
Package：Tray
Filter Type：-
Number of Lines：2
Current Rating (Max)：1.5A
DC Resistance (DCR) (Max)：-
Voltage Rating - DC：250V
Voltage Rating - AC：250V
Operating Temperature：-25°C ~ 120°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.906" L x 0.591" W (23.00mm x 15.00mm)
Height (Max)：1.004" (25.50mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：22.5 mH @ 10 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

VFWLF19-223T

Overview

The VFWLF19-223T is a fixed inductor manufactured by Allied Components International. It features a nominal inductance of 22.5 mH with a tolerance of +/-30%. The component belongs to the VFWLF19 series, which consists of industry-standard magnetic components designed for electronic circuit applications.

Feature Summary

Fixed inductance design within the VFWLF19 series
Standard industry form factor for integration

Applications

Electronic circuit filtering
Power supply input stages
Signal processing circuits

Procurement Notes

Verify the specific datasheet from Allied Components International or authorized distributors to confirm pinout, current ratings, and saturation characteristics. Ensure the +/-30% tolerance aligns with circuit requirements. Cross-reference the full part number to avoid confusion with similar series variants.

Selection Notes

Select this component when a 22.5 mH inductance value is required with moderate tolerance. Consider the physical size constraints of the VFWLF19 package. Evaluate DC resistance and current handling capabilities against the specific application load before finalizing the selection.

Part Context

Allied Components International produces a range of magnetic components and modules. The VFWLF19 series represents their standard inductor offerings. This specific model is one variant within that broader product line, distinguished by its 22.5 mH rating.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult manufacturer catalogs for direct equivalents or verify compatibility with alternative suppliers based on electrical specifications.
