VHB50W-Q24-S3R3

VHB50W-Q24-S3R3 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC DC CONVERTER 3.3V 50W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for VHB50W-Q24-S3R3

• Description：DC DC CONVERTER 3.3V 50W
• Series：VHB50W (50W)
• Mfr：CUI Inc.
• Package：Box
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：3.3V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：10A
• Power (Watts)：50 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature：-40°C ~ 100°C
• Efficiency：77%
• Mounting Type：Through Hole
• Package / Case：9-DIP Module, 1/2 Brick
• Size / Dimension：2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：EN, UL
• Standard Number：60950-1; 61000-3-2; 61000-3-3; 61000-6-1
• Grade：-
• Qualification：-
