VLF252012MT-150M

$0.73

Description：FIXED IND 15UH 630MA 680MOHM SMD
Series：VLF-M
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:60da6c1c0d96 Category: Fixed Inductors Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

VLF252012MT-150M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TDK Corporation. Its product description is FIXED IND 15UH 630MA 680MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for VLF252012MT-150M

Description：FIXED IND 15UH 630MA 680MOHM SMD
Series：VLF-M
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：15 µH
Tolerance：±20%
Current Rating (Amps)：630 mA
Current - Saturation (Isat)：330mA
Shielding：Shielded
DC Resistance (DCR)：680mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 105°C
Inductance Frequency - Test：1 MHz
Mounting Type：Surface Mount
Package / Case：1008 (2520 Metric)
Supplier Device Package：-
Size / Dimension：0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max)：0.047" (1.20mm)
Features：-

Fixed Inductors datasheet and documents for VLF252012MT-150M

VLF252012MT-150M

Fixed Inductors Overview

The TDK VLF252012MT-150M is a surface-mount power inductor designed for high-current applications. It features a ferrite core and shielded construction to minimize electromagnetic interference. The component measures 2.5 mm in length, 2.0 mm in width, and has a maximum height of 1.20 mm. It offers an inductance of 15 µH with a tolerance of ±20%. The device supports a maximum DC current of 780 mA and has a maximum DC resistance of 260 mOhms. It operates within a temperature range of -40°C to +105°C and is tested at a frequency of 1 MHz.

Fixed Inductors Feature Summary

Shielded magnetic structure reduces external magnetic field interference
Ferrite core material provides stable inductance characteristics
Compact SMD form factor suitable for space-constrained designs

Fixed Inductors Applications

Power supply circuits
DC-DC converter modules
General purpose electronic equipment

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official TDK documentation to ensure accuracy. Confirm that the required inductance value and current ratings align with the circuit design specifications before procurement. Check for any recommended alternative components if availability is limited. Ensure compliance with relevant environmental standards such as RoHS requirements specified in the datasheet.

Fixed Inductors Selection Notes

Select this component when a compact, shielded power inductor is required for surface-mount assembly. Consider the 2.5mm x 2.0mm footprint and 1.2mm height constraints. Evaluate the 780mA current rating and 260mOhm resistance against load requirements. Ensure the operating temperature range meets the application environment needs.

Fixed Inductors Part Context

This component belongs to TDK's VLF series of power inductors. The series is characterized by its shielded design and ferrite core construction. These inductors are intended for use in various electronic applications requiring reliable performance in compact spaces. The specific model indicates a 15µH inductance value within this product line.
