VLH322515-2R2M

Fixed Inductors Overview

The VLH322515-2R2M is a surface-mount power inductor from Viking Tech, featuring a ferrite core and rectangular package. It offers a nominal inductance of 2.2 µH with a maximum DC resistance of 126 mΩ. The component supports a maximum current rating of 790 mA and operates within a temperature range of -40 °C to 125 °C. Measuring 3.2 mm x 2.5 mm x 1.5 mm, it utilizes dual-ended terminals for SMD assembly.

Fixed Inductors Feature Summary

• Utilizes a special ferrite core for high impedance performance
• Features low DC resistance to minimize power loss
• Designed with a small size and low profile for compact applications

Fixed Inductors Applications

• Power supply circuits
• Timing circuits requiring accurate frequency output
• Low-power signal designs

Fixed Inductors Procurement Notes

Verify the specific ordering suffix and RoHS compliance status directly with the manufacturer or authorized distributors before procurement. Confirm that the component matches the required electrical specifications for your circuit design. Ensure availability through official channels to avoid counterfeit parts. Check for any recent updates to the datasheet regarding mechanical dimensions or thermal characteristics.

Fixed Inductors Selection Notes

Select this inductor when space constraints require a 1210 footprint with a 1.5 mm height limit. Choose based on the 2.2 µH inductance value and 790 mA current handling capability. Consider the low DC resistance for efficiency requirements. Verify compatibility with automated SMD placement processes due to the dual-ended terminal configuration.

Fixed Inductors Part Context

This component belongs to the VLH series of miniature power inductors manufactured by Viking Tech Corporation. The series is characterized by thin-film discrete passive components designed for general-purpose electronic applications. Viking Tech specializes in resistors, capacitors, and inductors for various industrial and consumer markets.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult the manufacturer for potential cross-reference options if this specific model is unavailable.
