VLMW41S1T2-6K7L-08

LED Indication - Discrete Overview

The VLMW41S1T2-6K7L-08 is a cool white surface-mount LED from Vishay Semiconductor Opto Division, housed in a PLCC-2 package. It operates with a typical forward voltage of 3.3V at a test current of 10mA. The component delivers a luminous intensity of 315mcd and features a wide 120-degree viewing angle. Physical dimensions include a 2.4mm round flat lens diameter within a 3.0mm x 2.8mm footprint.

LED Indication - Discrete Feature Summary

• Standard SMD PLCC-2 configuration for reliable surface mounting
• Cool white light emission optimized for indicator applications
• Wide 120-degree beam angle for broad visibility

LED Indication - Discrete Applications

• Panel status indicators
• Equipment power state signaling
• Control board activity lights

LED Indication - Discrete Procurement Notes

Verify the specific suffix against official Vishay documentation to confirm exact optical binning and thermal characteristics. Confirm RoHS compliance status through the manufacturer's latest release notes. Ensure the ordering part number matches the required lens transparency and color temperature specifications before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component when a standard cool white indicator is required in a compact PLCC-2 form factor. The 120-degree viewing angle provides effective visibility across wide angles. Verify that the 3.3V forward voltage aligns with the system's drive circuitry and current limiting requirements for stable operation.

LED Indication - Discrete Part Context

This device belongs to the VLMW41 series of standard surface-mount LEDs designed for general indication purposes. The PLCC-2 package offers a common footprint compatible with many existing PCB layouts. Vishay manufactures these components to provide consistent optical performance for industrial and consumer electronics applications.

LED Indication - Discrete Replacement Considerations

Consult Vishay official documentation for confirmed substitute part numbers. Cross-reference pinout compatibility and electrical parameters with alternative PLCC-2 white LEDs if direct substitution is necessary.
