VOA300-DEFG-X017T is listed in the Transistor, Photovoltaic Output Optoisolators range at ChipApex. The manufacturer field lists Vishay Semiconductor Opto Division. Its product description is OPTOISO 5.3KV 1CH PHVOLT 8-SMD. Review the specifications below when checking this part for your BOM.
Transistor, Photovoltaic Output Optoisolators specifications for VOA300-DEFG-X017T
- Description：OPTOISO 5.3KV 1CH PHVOLT 8-SMD
- Series：-
- Mfr：Vishay Semiconductor Opto Division
- Package：Tape & Reel (TR),Cut Tape (CT)
- Number of Channels：1
- Voltage - Isolation：5300Vrms
- Current Transfer Ratio (Min)：-
- Current Transfer Ratio (Max)：-
- Turn On / Turn Off Time (Typ)：-
- Rise / Fall Time (Typ)：800ns, 800ns
- Input Type：DC
- Output Type：Photovoltaic, Linearized
- Voltage - Output (Max)：-
- Current - Output / Channel：-
- Voltage - Forward (Vf) (Typ)：1.4V
- Current - DC Forward (If) (Max)：60 mA
- Vce Saturation (Max)：-
- Operating Temperature：-40°C ~ 125°C
- Mounting Type：Surface Mount
- Package / Case：8-SMD, Gull Wing
- Supplier Device Package：8-SMD
- Grade：Automotive
- Qualification：AEC-Q102
Transistor, Photovoltaic Output Optoisolators datasheet and documents for VOA300-DEFG-X017T
Transistor, Photovoltaic Output Optoisolators Overview
The VOA300-DEFG-X017T is a linear optocoupler from Vishay Semiconductor Opto Division, designed for automotive applications. It features an infrared emitter and isolated feedback/output PIN diodes. Key electrical parameters include a 5300Vrms isolation voltage, 1 channel, and SMD-8 package. Rise/fall times are 0.8 µs. Forward current is 10 mA, forward voltage 1.4 V, reverse voltage 5 V, and power dissipation 100 mW. Operating temperature range is -40°C to +125°C. AEC-Q102 qualified.
Transistor, Photovoltaic Output Optoisolators Feature Summary
- Automotive-grade linear optocoupler with fast response and gain stability
- High isolation voltage of 5300Vrms for enhanced safety
- Integrated isolated feedback loop for precise linearity
Transistor, Photovoltaic Output Optoisolators Applications
- Voltage sensing in automotive systems
- Current sensing in automotive environments
- Isolated feedback control circuits
Transistor, Photovoltaic Output Optoisolators Procurement Notes
Verify the specific suffix DEFG against official Vishay documentation to confirm pinout and internal configuration. Ensure compatibility with AEC-Q102 requirements if used in automotive designs. Cross-reference datasheet revision dates to avoid obsolete versions. Confirm surface-mount soldering profiles match the SMD-8 package specifications provided in the manufacturer's guidelines.
Transistor, Photovoltaic Output Optoisolators Selection Notes
Select this component when high isolation voltage and linear performance are critical. The integrated feedback mechanism ensures stable transfer gain over temperature variations. Suitable for applications requiring fast response times and robust automotive qualification. Consider thermal management within the specified power dissipation limits during design.
Transistor, Photovoltaic Output Optoisolators Part Context
Part of the VOA300 series, optimized for automotive use. Offers improved isolation and linearity compared to standard optocouplers. Designed for reliable operation in harsh automotive environments with wide temperature ranges.
Transistor, Photovoltaic Output Optoisolators Replacement Considerations
Check for direct substitutes within the VOA300 family or other AEC-Q102 qualified linear optocouplers with similar isolation and speed characteristics. Verify pin compatibility and electrical parameters before substitution.
