VS-T20HF220

Single Diodes Overview

The VS-T20HF220 is a high-voltage power rectifier diode from Vishay’s FRED Pt® series, housed in a D-55 T-Module package. It features a maximum repetitive reverse voltage of 2200 V and an average rectified forward current of 20 A. The device operates within a junction temperature range of -40°C to 150°C. Key electrical characteristics include a maximum reverse leakage current of 18 mA at 2200 V. This component is designed for robust performance in demanding industrial power applications requiring high voltage isolation.

Single Diodes Feature Summary

• Features an electrically isolated base plate for simplified mechanical design and rapid assembly
• Utilizes FRED Pt® technology for optimized switching performance
• Complies with UL approval file E78996 for safety standards

Single Diodes Applications

• Industrial power supplies
• High-voltage DC-DC converters
• Inverter circuits

Single Diodes Procurement Notes

Verify the specific suffix codes against the official datasheet to ensure correct packaging and compliance status. Confirm that the D-55 module form factor matches your thermal management and mounting requirements. Cross-reference the UL file number E78996 if regulatory certification is mandatory for your end product. Ensure sourcing channels provide genuine Vishay components to guarantee specified electrical parameters.

Single Diodes Selection Notes

Select this component when applications require a 2200 V blocking capability combined with a 20 A continuous current rating. The T-Module package is suitable for chassis mounting where high thermal dissipation and electrical isolation are critical. Consider the 18 mA reverse leakage specification for high-voltage standby conditions. Evaluate the junction temperature limit of 150°C against your system's thermal profile to ensure reliable long-term operation under load.

Single Diodes Part Context

This part belongs to Vishay’s FRED Pt® (Fast Recovery Epitaxial Diode) family, which utilizes platinum doping to control carrier lifetime. The T-Module designation indicates a standardized industrial housing designed for easy integration into larger power assemblies. The D-55 package provides a compact footprint while maintaining high voltage isolation capabilities essential for medium-to-high power electronic systems.

Single Diodes Replacement Considerations

Consult official Vishay documentation for direct cross-references. Verify that any substitute maintains the 2200 VRRM and 20A Io ratings. Ensure the replacement also offers an electrically isolated base plate and compatible D-55 mechanical dimensions. Check for equivalent reverse recovery characteristics to maintain circuit stability.
