VTC100-4R7M-RC is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Allied Components International. Its product description is 4.7UH 20% Vrt Mnt Toroidal Chok. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for VTC100-4R7M-RC
- Description：4.7UH 20% Vrt Mnt Toroidal Chok
- Series：TC100
- Mfr：Allied Components International
- Package：Tray
- Type：Toroidal
- Material - Core：-
- Inductance：4.7 µH
- Tolerance：±20%
- Current Rating (Amps)：5:00 AM
- Current - Saturation (Isat)：6.5A
- Shielding：Unshielded
- DC Resistance (DCR)：10mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 105°C
- Inductance Frequency - Test：1 kHz
- Mounting Type：Through Hole
- Package / Case：Radial, Vertical (Open)
- Supplier Device Package：Radial
- Size / Dimension：0.600" Dia (15.24mm)
- Height - Seated (Max)：-
- Features：-
Fixed Inductors datasheet and documents for VTC100-4R7M-RC
Fixed Inductors Overview
The VTC100-4R7M-RC is a toroidal choke manufactured by Allied Components International. It features a general-purpose inductor design with a nominal inductance of 4.7 µH and a tolerance of ±20%. The component utilizes a vertical mounting configuration with wire terminals, suitable for through-hole applications. It operates within a temperature range of -55 °C to +105 °C and complies with RoHS standards.
Fixed Inductors Feature Summary
- Toroidal magnetic core construction
- Vertical mounting orientation
- RoHS compliant manufacturing
Fixed Inductors Applications
- General purpose filtering circuits
- Power supply input stages
- Signal conditioning networks
Fixed Inductors Procurement Notes
Verify the specific manufacturer designation on the component body against official Allied Components International documentation. Confirm that the ordering suffix matches the required inductance value and tolerance specifications. Ensure the vertical package dimensions align with the target PCB footprint requirements before finalizing procurement orders.
Fixed Inductors Selection Notes
Select this component for applications requiring moderate inductance values in vertical configurations. Consider the operating temperature range and current handling capabilities relative to the circuit design. Verify compatibility with automated insertion processes if high-volume production is planned.
Fixed Inductors Part Context
This part belongs to the VTC series of toroidal chokes from Allied Components International. The series offers various inductance values tailored for general electronic applications. The VTC100 variant specifically addresses needs for compact vertical mounting solutions in standard industrial electronics.
Fixed Inductors Replacement Considerations
Cross-reference with Allied Electronics part numbers such as VTC100-4R7N-RC or similar variants within the same series for equivalent electrical characteristics. Consult manufacturer substitution guides for verified alternatives.
