VTEUMLJANF-10.000000

Oscillators Overview

The Taitien VTEUMLJANF-10.000000 is a Voltage-Controlled Crystal Oscillator (VCXO) operating at a nominal frequency of 10.000 MHz. It utilizes CMOS output logic and requires a supply voltage of 3.3V. The device offers a frequency stability of ±50ppm and functions within an operating temperature range of -40°C to +85°C. It is housed in a compact 10-SMD, No Lead package with an exposed pad, measuring 7.00mm x 5.00mm in dimension and having a maximum seated height of 0.083 inches.

Oscillators Feature Summary

• Voltage-controlled crystal oscillator architecture for frequency tuning applications
• CMOS output interface compatible with standard digital logic levels
• Compact surface-mount ceramic package designed for automated assembly

Oscillators Applications

• Communication systems requiring precise frequency control
• Data transmission equipment needing stable clock signals
• Test and measurement instruments utilizing VCXO technology

Oscillators Procurement Notes

Verify the specific datasheet version for the VTEUMLJANF-10.000000 to confirm current electrical characteristics and mechanical drawings. Ensure compatibility with your system's power supply requirements and thermal management needs. Cross-reference the pinout configuration against your PCB layout design to prevent installation errors. Confirm that the CMOS output voltage levels align with your receiving circuitry specifications.

Oscillators Selection Notes

Select this component when a voltage-tunable crystal oscillator is required for 10 MHz applications. The ±50ppm stability suits general-purpose timing needs rather than high-precision references. Consider the 3.3V supply constraint and CMOS output drive capability. The 10-SMD package size fits space-constrained designs. Evaluate if the operating temperature range meets your environmental conditions.

Oscillators Part Context

Taitien manufactures frequency control components including oscillators, TCXOs, and VCXOs. This model belongs to their SMD oscillator lineup, characterized by small form factors suitable for modern electronics. The company emphasizes low power consumption and reliability for industrial and consumer markets.

Oscillators Replacement Considerations

Direct substitutes include other 10MHz VCXOs with similar CMOS outputs and 3.3V operation. Verify pin compatibility and frequency stability requirements before swapping. Check if alternative packages like 4-SMD or 6-SMD are acceptable for your design constraints.
