VZH101M1CTR-0606CS

VZH101M1CTR-0606CS is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists SURGE. Its product description is CAP ALUM 100UF 20% 16V SMD. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for VZH101M1CTR-0606CS

• Description：CAP ALUM 100UF 20% 16V SMD
• Series：VZH
• Mfr：SURGE
• Package：Tape & Reel (TR),Strip
• Capacitance：100 µF
• Tolerance：±20%
• Voltage - Rated：16 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：2000 Hrs @ 105°C
• Operating Temperature：-55°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：-
• Ripple Current @ High Frequency：230 mA @ 100 kHz
• Lead Spacing：-
• Size / Dimension：0.248" Dia (6.30mm)
• Height - Seated (Max)：0.236" (6.00mm)
• Surface Mount Land Size：0.260" L x 0.260" W (6.60mm x 6.60mm)
• Mounting Type：Surface Mount
• Package / Case：Radial, Can - SMD
• Impedance：340 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for VZH101M1CTR-0606CS
