WCI2520CPR10GDG

$0.09

Description：CHIP IND 2520,100NH,G,60Q,0.65A,
Series：WCI2520CP
Mfr：INPAQ Technology Co., Ltd
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:661b3248d897 Category: Fixed Inductors Brand: INPAQ Technology Co., Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

WCI2520CPR10GDG is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists INPAQ Technology Co., Ltd. Its product description is CHIP IND 2520,100NH,G,60Q,0.65A,. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for WCI2520CPR10GDG

Description：CHIP IND 2520,100NH,G,60Q,0.65A,
Series：WCI2520CP
Mfr：INPAQ Technology Co., Ltd
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Wirewound
Material - Core：Ceramic
Inductance：100 nH
Tolerance：±2%
Current Rating (Amps)：650 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：560mOhm Max
Q @ Freq：60 @ 350MHz
Frequency - Self Resonant：1GHz
Ratings：-
Operating Temperature：-25°C ~ 125°C
Inductance Frequency - Test：25 MHz
Mounting Type：Surface Mount
Package / Case：1008 (2520 Metric)
Supplier Device Package：1008
Size / Dimension：0.115" L x 0.110" W (2.92mm x 2.79mm)
Height - Seated (Max)：0.080" (2.03mm)
Features：-

Fixed Inductors datasheet and documents for WCI2520CPR10GDG

WCI2520CPR10GDG

Fixed Inductors Overview

The WCI2520CPR10GDG is a fixed wirewound inductor manufactured by INPAQ Technology Co., Ltd. It features an unshielded construction with a ceramic core, housed in a 1008 (2520 Metric) package. The component provides an inductance of 100 nH with a tolerance of ±2%. It supports a maximum current rating of 650 mA and exhibits a maximum DC resistance of 560 mOhm.

Fixed Inductors Feature Summary

Utilizes ceramic core wirewound construction for stable performance.
Offers high Q factor characteristics suitable for RF applications.
Provides wide range of inductance selection within the series.

Fixed Inductors Applications

RF circuits
High-frequency signal processing
Communication equipment

Fixed Inductors Procurement Notes

Verify the specific suffix codes against official datasheets to confirm exact electrical tolerances and packaging configurations. Ensure compatibility with surface mount assembly processes. Confirm RoHS compliance status through manufacturer documentation before procurement integration.

Fixed Inductors Selection Notes

Select this component for applications requiring precise 100 nH inductance in compact spaces. Consider the unshielded nature for layout sensitivity. Evaluate thermal management requirements based on the 650 mA current rating and 560 mOhm resistance specifications.

Fixed Inductors Part Context

This part belongs to INPAQ's wirewound ceramic RF inductor line. These components are designed for computing, communication, and consumer electronics markets. The series emphasizes exceptional Q factors and wide inductance ranges from 10 to 15000 nH.

Fixed Inductors Replacement Considerations

Check for direct substitutes within the same series or package size. Verify equivalent inductance, tolerance, and current ratings. Cross-reference pinout and footprint dimensions to ensure mechanical compatibility without circuit redesign.
