WCL3225-820-R

$0.10

Description：FIXED IND 82UH 100MA 5.6 OHM SMD
Series：WCL3225
Mfr：Eaton - Electronics Division
Package：Tape & Reel (TR)

SKU:4d4bdc1513d2 Category: Fixed Inductors Brand: Eaton - Electronics Division

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

WCL3225-820-R is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Eaton - Electronics Division. Its product description is FIXED IND 82UH 100MA 5.6 OHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for WCL3225-820-R

Description：FIXED IND 82UH 100MA 5.6 OHM SMD
Series：WCL3225
Mfr：Eaton - Electronics Division
Package：Tape & Reel (TR)
Type：Drum Core, Wirewound
Material - Core：Ceramic
Inductance：82 µH
Tolerance：±5%
Current Rating (Amps)：100 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：5.6Ohm Max
Q @ Freq：10 @ 2.52MHz
Frequency - Self Resonant：5MHz
Ratings：-
Operating Temperature：-40°C ~ 85°C
Inductance Frequency - Test：2.52 MHz
Mounting Type：Surface Mount
Package / Case：1210 (3225 Metric)
Supplier Device Package：1210
Size / Dimension：0.138" L x 0.114" W (3.50mm x 2.90mm)
Height - Seated (Max)：0.089" (2.25mm)
Features：-
