Product Detailed Parameters
- Description：CMC 3A 2LN 1.3 KOHM SMD
- Series：WCM7060FASF
- Mfr：TAI-TECH Advanced Electronics Co., Ltd.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：3A
- DC Resistance (DCR) (Max)：20mOhm
- Voltage Rating - DC：80V
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 125°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Surface Mount
- Size / Dimension：0.276" L x 0.236" W (7.00mm x 6.00mm)
- Height (Max)：0.150" (3.80mm)
- Package / Case：Horizontal, 4 PC Pad
- Inductance @ Frequency：-
- Impedance @ Frequency：1.3 kOhms @ 100 MHz
Download product information
Overview
The WCM7060FASF-132-LM is a wire wound power common mode filter manufactured by TAI-TECH Advanced Electronics Co., Ltd. It belongs to the WCM7060FASF series and is designed for power line filtering applications. The component features a surface mount mounting type with a compact SMD-4P package measuring 7.00mm x 6.00mm. It has a DC voltage rating of 80V and operates within a temperature range of -40°C to +125°C.
Feature Summary
- Constructed using wire wound technology for robust power line filtering performance
- Designed specifically for power line circuit noise suppression
- Engineered for surface mount assembly on printed circuit boards
Applications
- Power line filtering in electronic equipment
- Noise suppression in automotive electronics systems
- EMI reduction in industrial power supplies
Procurement Notes
Verify the manufacturer part number against official TAI-TECH documentation to ensure authenticity. Confirm that the specific suffix matches the required electrical characteristics, as variations may exist within the series. Cross-reference the package dimensions and pin configuration with your PCB design files before finalizing procurement orders.
Selection Notes
Select this component when a surface mount common mode choke with an 80V DC rating is required. Ensure the operating environment stays within the specified -40°C to +125°C temperature range. Verify that the 7.00mm x 6.00mm footprint fits the available board space and that the wire wound construction meets the necessary inductance requirements for the target application.
Part Context
This component is part of the WCM7060FASF series from TAI-TECH Advanced Electronics Co., Ltd., established in 1998. The company specializes in laminated chips, precision wire wound components, and integrated solutions. This specific model serves as a passive electromagnetic interference suppression device for modern electronic designs requiring compact power line filtering.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source material. Consult the manufacturer's datasheet or authorized distributors for qualified alternatives if this specific part number is unavailable.
