WP7113LID

LED Indication - Discrete Overview

The Kingbright WP7113LID is a single-color red LED component belonging to the WP7113 series. It utilizes a T-1 3/4 (5 mm) through-hole package with a water-clear lens and a dome shape. The device emits light at a peak wavelength of 625 nm. Key electrical parameters include a forward voltage of 2.2 V, a maximum power dissipation of 84 mW, and a maximum forward current rating of 20 mA. The optical output provides an intensity of 10,000 mcd with a viewing angle of 20 degrees. It operates within a temperature range of -40 °C to +85 °C.

LED Indication - Discrete Feature Summary

• Features a high-intensity red emission suitable for indicator applications
• Constructed with a water-clear dome lens for focused light transmission
• Designed for standard through-hole mounting on printed circuit boards

LED Indication - Discrete Applications

• Panel indicators
• Instrumentation displays
• Control equipment status lights

LED Indication - Discrete Procurement Notes

Verify the specific suffix 'LID' against manufacturer datasheets to confirm lens treatment and binning specifications. Ensure compatibility with existing PCB footprints for the 5 mm T-1 3/4 package. Check RoHS compliance documentation for regulatory requirements in target markets.

LED Indication - Discrete Selection Notes

Select this component when a bright red indication is required with a narrow viewing angle. Compare the 10,000 mcd intensity against lower brightness variants if visibility conditions differ. Confirm that the 2.2 V forward voltage aligns with the driving circuit design constraints.

LED Indication - Discrete Part Context

This part belongs to the Kingbright WP7113 family of 5 mm LEDs. The series offers various colors and lens options. The WP7113LID specifically denotes the red variant with defined optical characteristics. It serves as a standard discrete component for general electronic signaling tasks.

LED Indication - Discrete Replacement Considerations

Direct substitutes may include other Kingbright 5 mm red LEDs from the same series with matching electrical ratings. Verify pinout orientation and mechanical dimensions before substitution.
