WP9294SECK/J3

LED Indication - Discrete Overview

The WP9294SECK/J3 is a single-color red LED from Kingbright, utilizing AlGaInP technology on a GaAs substrate. It features a 5mm (T1 3/4) dome lens with water-clear transparency and a 130-degree viewing angle. Key electrical parameters include a forward voltage of 2.2V at 20mA and an optical intensity of 600 mcd. The component operates within a temperature range of -40°C to +85°C and is supplied in bulk packaging.

LED Indication - Discrete Feature Summary

• High-intensity red light emission optimized for industrial applications
• Wide 130-degree viewing angle for enhanced visibility
• Water-clear dome lens design for effective light transmission

LED Indication - Discrete Applications

• Industrial equipment status indication
• Panel-mounted visual signaling
• General-purpose electronic device indicators

LED Indication - Discrete Procurement Notes

Verify the specific suffix J3 against official Kingbright documentation to confirm lead time and compliance requirements. Ensure ordering quantities align with manufacturer minimums and check RoHS3 certification status prior to procurement.

LED Indication - Discrete Selection Notes

Select this component when a high-brightness red indicator with a wide dispersion angle is required. The 5mm through-hole package suits standard PCB layouts, while the 20mA drive current ensures compatibility with common logic-level drivers.

LED Indication - Discrete Part Context

This part belongs to Kingbright's discrete LED lineup, specifically designed for reliable visual feedback in harsh environments. The WP9294 series offers durability and consistent performance, distinguishing it from lower-intensity general-purpose LEDs.

LED Indication - Discrete Replacement Considerations

Cross-reference with WP9294SYC/J3 for yellow variants or WP7113SECK/J3 for higher intensity options. Verify pinout and mechanical dimensions before substituting.
