WPN252010UR33MTY02

Fixed Inductors Overview

The WPN252010UR33MTY02 is a shielded drum core wirewound inductor manufactured by Shenzhen Sunlord Electronics. It features an inductance of 330 nH and supports a current rating of 4 A with a maximum DC resistance of 30 mOhm. The component utilizes a 1008 (2520 Metric) surface-mount package, designed for high-current power applications requiring compact form factors.

Fixed Inductors Feature Summary

• Shielded drum core construction to minimize electromagnetic interference
• Wirewound technology for stable performance under load
• High current handling capability suitable for power circuits

Fixed Inductors Applications

• Noise suppression for power lines
• Large current signal processing in computer peripherals
• Power adapter circuits
• LCD display power management

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct tolerance and packaging specifications. Confirm that the 1008 package dimensions align with your PCB footprint requirements before finalizing orders.

Fixed Inductors Selection Notes

Select this component when designing circuits requiring low inductance values combined with high current capacity. The 30 mOhm resistance minimizes power loss, making it suitable for efficient power delivery systems where space constraints necessitate a 1008 package.

Fixed Inductors Part Context

This part belongs to Sunlord's wirewound SMD power inductor portfolio. The company specializes in passive components including chip inductors and beads, serving sectors such as communications, consumer electronics, and automotive applications with a focus on miniaturization and reliability.

Fixed Inductors Replacement Considerations

Consult official cross-reference lists for compatible shielded drum core inductors with matching 330 nH inductance and 4 A current ratings in 1008 packages.
