WRFI0603-S-R16JT-CT

WRFI0603-S-R16JT-CT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Venkel. Its product description is Wirewound RF Inductor,0603,160nH. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for WRFI0603-S-R16JT-CT

• Description：Wirewound RF Inductor,0603,160nH
• Series：WRFI
• Mfr：Venkel
• Package：Strip
• Type：Wirewound
• Material - Core：Ceramic
• Inductance：160 nH
• Tolerance：±5%
• Current Rating (Amps)：280 mA
• Current - Saturation (Isat)：-
• Shielding：-
• DC Resistance (DCR)：1.4Ohm
• Q @ Freq：25 @ 100MHz
• Frequency - Self Resonant：1.3GHz
• Ratings：-
• Operating Temperature：-40°C ~ 125°C
• Inductance Frequency - Test：100 MHz
• Mounting Type：Surface Mount
• Package / Case：0603 (1608 Metric)
• Supplier Device Package：0603 (1608 Metric)
• Size / Dimension：0.071" L x 0.044" W (1.80mm x 1.12mm)
• Height - Seated (Max)：0.040" (1.02mm)
• Features：-

Fixed Inductors datasheet and documents for WRFI0603-S-R16JT-CT
