X1005324-LWS5SX10A2

$136.24

Description：ANTENNA GNSS / LTE MIMO / WIFI
Series：-
Mfr：KYOCERA AVX
Package：Box

SKU:1a7c6682de59 Category: RF Antennas Brand: KYOCERA AVX

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

X1005324-LWS5SX10A2 is listed in the Antennas RF range at ChipApex. The manufacturer field lists KYOCERA AVX. Its product description is ANTENNA GNSS / LTE MIMO / WIFI. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for X1005324-LWS5SX10A2

Description：ANTENNA GNSS / LTE MIMO / WIFI
Series：-
Mfr：KYOCERA AVX
Package：Box
RF Family/Standard：Cellular, Navigation, WiFi
Frequency Group：Wide Band
Frequency (Center/Band)：829MHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.94GHz, 2.495GHz, 2.45GHz, 5.4875GHz
Frequency Range：698MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz, 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.825GHz
Antenna Type：Dome
Number of Bands：8
VSWR：1.8, 2, 3.5
Return Loss：-
Gain：3.8dBi, 3dBi, 3dBi, 3.5dBi, 4.9dBi, 4.1dBi, 4.6dBi, 6.6dBi
Features：Cable - 1m, LNA
Termination：SMA Male (2), RP-SMA Male (1)
Ingress Protection：IPX7
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：2.500" (63.50mm)
Applications：GLONASS, GPS, GNSS, LTE, Wi-Fi
Power - Max：-

Antennas RF datasheet and documents for X1005324-LWS5SX10A2

X1005324-LWS5SX10A2

Antennas RF Overview

The X1005324-LWS5SX10A2 is an external omnidirectional RF antenna manufactured by KYOCERA AVX, designed for WiFi applications. It features a circular disc physical form factor and utilizes an SMA male connector for signal transmission. The operational frequency range spans from 698 MHz to 5850 MHz, supporting broad band coverage. The unit includes a 1-meter lead length and employs adhesive foam mounting combined with screw/nut hardware for secure installation. Standard certifications include REACH and RoHS compliance.

Antennas RF Feature Summary

Supports multi-band operation covering frequencies from 698 MHz to 5850 MHz
Combines adhesive foam and screw/nut mounting for stable installation
Features an external omnidirectional radiation pattern
Includes a 1-meter lead length with SMA male connector

Antennas RF Applications

Industrial IoT deployments
Retail environment connectivity
Remote monitoring systems
Automotive communication modules

Antennas RF Procurement Notes

Verify the specific ordering suffix against official KYOCERA AVX documentation to ensure correct configuration. Confirm that the SMA male connector polarity matches system requirements. Check for REACH and RoHS certification status if regulatory compliance is mandatory for the target market. Ensure the operating temperature range of -40°C to +85°C aligns with environmental conditions.

Antennas RF Selection Notes

Select this component when a robust external antenna solution is required for WiFi and LTE bands up to 5850 MHz. The dual-mounting design offers flexibility for various enclosure types. Consider the 1-meter cable length for routing constraints. Validate that the circular disc form factor fits within the available spatial envelope without obstructing other components or affecting radiation patterns.

Antennas RF Part Context

This model belongs to the external antenna portfolio from KYOCERA AVX, targeting diverse environments including industrial and automotive sectors. It complements other multi-band solutions in the lineup by offering extended frequency coverage up to 5850 MHz. The product emphasizes durability and versatile mounting options to support reliable connectivity in challenging deployment scenarios.
