XC6217A142GR-G

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The XC6217A142GR-G is a fixed-output low dropout regulator from Torex Semiconductor, providing a nominal output voltage of 1.4V with a standard accuracy tolerance. It supports a maximum continuous output current of 200mA and operates within an input voltage range of 1.6V to 6.0V. The device features a Green Operation function that automatically switches between High Speed and Power Save modes based on load conditions. It utilizes a USP-4D surface-mount package and includes built-in protection against overcurrent and thermal overload.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

• Green Operation function enables automatic switching between high-speed operation and power-save mode to optimize efficiency across varying load currents.
• Integrated CL auto-discharge circuitry allows for rapid discharge of the output capacitor when the control pin is deactivated.
• Foldback current limiting circuit provides short-circuit protection by reducing output current as the output voltage drops.
• Compatible with low ESR ceramic capacitors due to internal phase compensation design.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

• Smart phones
• Portable game consoles
• Digital still cameras

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific ordering suffix matches the required package type and environmental compliance standards. Confirm that the selected output voltage variant aligns with the target application's power requirements. Ensure input and output capacitor values meet the stability criteria specified in the datasheet to prevent oscillation during operation.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this component for applications requiring precise fixed voltage regulation with minimal quiescent current consumption. The Green Operation feature makes it suitable for battery-powered devices where efficiency at light loads is critical. Ensure the input voltage remains above the minimum threshold to maintain regulation under all operating conditions.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This part belongs to the XC6217 series of high-speed LDO voltage regulators manufactured using CMOS process technology. The series is designed for portable electronic equipment requiring stable power supply with low noise characteristics. The A-type designation indicates the presence of a Green Operation pin without integrated output capacitor discharge functionality.
