XC6VHX380T-2FFG1923I

Field Programmable Gate Array Overview

The AMD XC6VHX380T-2FFG1923I is a high-performance Field Programmable Gate Array (FPGA) belonging to the Virtex-6 HXT family. It features a 40nm process technology optimized for high-speed serial communications and complex logic applications. The device provides 379,200 system logic cells and supports up to 720 user I/Os. It integrates 15.3 Mb of embedded block RAM and includes 160 DSP slices for advanced signal processing tasks. The component operates within a supply voltage range of 0.95 V to 1.05 V and is housed in a 1924-ball FCBGA package with a -40°C to +100°C operating temperature range.

Field Programmable Gate Array Feature Summary

• High-density logic architecture designed for demanding digital signal processing and data path applications
• Integrated high-speed transceivers supporting multi-gigabit serial communication standards
• Advanced power management capabilities with multiple voltage domains for optimized energy efficiency

Field Programmable Gate Array Applications

• High-speed networking equipment and telecommunications infrastructure
• Industrial automation and control systems requiring real-time processing
• Medical imaging systems and diagnostic equipment
• Aerospace and defense radar signal processing

Field Programmable Gate Array Procurement Notes

Verify the specific suffix 'I' indicates industrial temperature rating during sourcing. Confirm package integrity upon receipt as FCBGA components are sensitive to mechanical stress. Ensure compatibility with existing design tools and bitstream formats before mass procurement. Request original manufacturer documentation to validate authenticity and traceability.

Field Programmable Gate Array Selection Notes

Select this model when high logic density and extensive I/O capacity are required for complex system integration. Consider the Virtex-6 HXT series for applications needing robust DSP resources alongside high-speed serial interfaces. Evaluate thermal management requirements due to the high performance density of the 40nm node. Compare against lower-tier Virtex-6 variants if cost constraints limit the need for maximum logic resources.

Field Programmable Gate Array Part Context

This component is part of the AMD (formerly Xilinx) Virtex-6 FPGA portfolio, specifically the High-Speed Transceiver (HXT) variant. The Virtex-6 series represents a significant generation in adaptive computing, offering enhanced performance over previous Spartan and Virtex-5 lines. The HXT designation highlights its specialization in high-bandwidth serial connectivity and large-scale logic implementation for enterprise-grade applications.

Field Programmable Gate Array Replacement Considerations

Direct pin-to-pin replacements may include other Virtex-6 HXT devices with compatible package sizes, such as the XC6VHX380T-1FFG1923I or XC6VHX565T variants if higher capacity is acceptable. Verify electrical specifications and timing constraints carefully when substituting across speed grades or logic densities.
